The 4" Mega-Tent Beam Clamp is designed for robust and secure attachment to free span tent beams, utilizing the Keder track slot for a reliable fit. Its unique construction includes a centered hole for shackle attachment and additional holes for Mega-Couplers, facilitating versatile mounting options. Crafted from high-quality materials, including triple steel shafts and aircraft grade aluminum, this clamp is engineered for strength and precision. The clamp's design ensures that loads are always centered on the beam, with a one-ton design load rating that necessitates approval from the tent manufacturer for specific load, tent beam, and span configurations.

• Opening Width: Opens 5-1/4" to fasten securely into the Keder track slot.
• Engagement: Engages the Keder track slot on both sides for 4 inches.
• Attachment Points: Centered hole for a 5/8 inch shackle; two drilled and tapped 1/2" inch 13 tpi holes for attaching Mega-Couplers.
• Shafts: Triple steel shafts, three quarters of an inch thick. The central shaft is threaded with a fine pitch left and right thread and has a captive vise style handle.
• Material: Load attachment block and jaws CNC machined from aircraft grade aluminum.
• Design Load: Rated for up to one ton design load, with load and span approval required from the tent manufacturer.
• Weight: 5.25 lbs.
• Order Code: MTBC4 (Mega Tent Beam Clamp 4 Inch, Silver).
