The fastest, smartest console ever created, Quantum 7 delivers the functionality, audio performance and sheer scale required to deliver the largest productions now and in the future. With Quantum 7, you have the power to tackle any challenge and truly own the room.
Built to exceed the ambitions of tomorrow’s touring productions, Quantum 7 breaks the barrier of seventh generation FPGA technology to deliver a dramatic leap forward in power and connectivity. All of this can be added to your existing SD7 surface, ensuring rental partners benefit from an even longer return on investment.
The result is a revolution of possibilities that towers above every other mixing platform available today.
- Faders
- 38 x 100mm touch-sensitive, motorised
- 14 x 60mm touch sensitive, motorised
- Screens
- 3 x 15” LCD high-resolution touch screens
- Meterbridge
- 3 x Custom Mounted LCD high-resolution TFT-LCD screens
- Redundancy
- Internal removable engine x 2
- Internal hot-swappable PSU x 2
- Processing Channels
- Up to 432 (combination of Input Channels / Aux / Solo Group Busses)
- Busses
- Up to 128 Aux / Group busses with full processing Mono / Stereo / LCR / 5.1
- Matrix
- Up to 48 Input / 48 Outputs with full processing
- Control Groups
- Up to 36, selectable for VCA-style, Moving fader, Mute Group
- Graphic Eq
- 48 x 32-band, Gain +/- 12dB
- Internal FX
- Up to 48 stereo effects comprising 16 floating point reverbs and 32 delay/chorus/pitch/enhancer
- Local I/O
- 12 x mic/line I/O, 12 x AES I/O
- 8 x MADI interfaces @ 48kHz, 4 redundant interfaces @ 96kHz, BNC connectivity
- Standard Optocore (Dual Loop – Optional)
- Sampling rates: 48kHz / 96kHz
- GPIO: 2 x DSub37 – 16 as standard, expandable to 32
- Video Inputs x 2, Outputs x 2
- DMI: 2 x DiGiCo Multichannel Interface
- Waves: Fitted as Standard
- Ext Sync: Wordclock, AES, Video, MADI, Optocore
- Quantum 7 Dimensions: 1496mm (w) x 875mm (d) x 503mm (h)
- Quantum 7 Weight: 141Kg / 311lbs (245Kg / 540 lbs. with flightcase)
- Quantum 7 Flightcase: 1600mm (w) x 600mm (d) x 1240mm (h)
- Power Requirements: 90V-260V, 50-60Hz, 600VA
