L-Acoustics 5XT

L-Acoustics 5XT


Rate Calculator

Product Highlights

  • Compact Design: The 5XT is a 2-way passive coaxial enclosure, ensuring studio quality in near-field applications.
  • High Performance: It boasts an exceptional output-to-size ratio, making it powerful despite its small size.
  • Consistent Sound Quality: Features smooth off-axis response, thanks to its coaxial technology.
  • Economical: Offers high enclosure density per amplified controller, making it a cost-effective solution.
View full details

The 5XT from L-Acoustics is a testament to the adage "good things come in small packages." This 2-way passive coaxial enclosure, first introduced in 1989, brings studio quality to near-field applications, making it ideal for event organizers and planners.

Its exceptional output-to-size ratio ensures powerful performance, while the smooth off-axis response provided by its coaxial technology guarantees consistent sound quality.

Additionally, its economic design allows for a high enclosure density per amplified controller, making it a cost-effective choice for various events.

  • Type: 2-way passive coaxial enclosure
  • Max SPL: 121 dB
  • Bandwidth: 95 Hz - 20 kHz
  • Transducers:
    • LF: 1 x 5"
    • HF: 1 x 1"
  • Weight: 3.5 kg / 7.7 lb
  • Directivity: H: 110°, V: 110°
  • Nominal Impedance: 16 Ω
  • Connectors:
    • IN: 1 x 4-point speakON
    • LINK: 1 x 4-point speakON
    • IN/LINK: 2 x 2-point screw terminals
  • Rigging and Handling:
    • 2 M6 inserts for ETR5
    • 1 x 3/8” insert for microphone stand
  • Cabinet Material: Premium grade Baltic birch plywood, steel with anti-corrosion coating
  • Finish Options:
    • Dark grey brown Pantone 426 C
    • Pure white RAL 9010
    • Custom RAL code on special order
  • Protection: IP30
